Error code
U-Line error code Evap T Short
U-Line error code Evap T Short: The evaporator thermistor circuit is shorted. Which machines can actually raise it, where the number lives on this make, and what to do next.
- From $95 diagnostic, credited to the repair
- 59 cities and neighborhoods covered
- OEM parts available on order
- In writing the price, before anything is opened
What we can confirm
Code Evap T Short, from the manufacturer's own documentation
A code is only meaningful together with the machine showing it — the same digits mean different things on different equipment.
The code
Evap T Short
The evaporator thermistor circuit is shorted. The same sensor as Evap T Open and the opposite failure: the cable is pinched or crushed rather than broken or disconnected. Unlike the E numbers on the rest of this make, this one is shown to you: the 3000 Series monitors its inputs continuously and puts the notification on the user interface rather than only into a service log.
or call (305) 851-2207
What it narrows down to
The evaporator sensor circuit is shorted
Diagnostic
From $95, credited to the repair
On the same appliance
What else belongs to the beverage centers
On this make a code belongs to the appliance rather than to a product line. These are the other conditions this machine can display, and the models that can show this one — a display often has more than one thing to say, and the model number decides what any of it costs to put right.
Other codes this appliance can display
Door 1, the upper door on a two-door
Door 2 — the lower door of a
Thermistor 1 open. In plain terms, the cabinet
Thermistor 2 open. In plain terms, the evaporator
Thermistor 3 open. In plain terms, the third
Thermistor 1 shorted. In plain terms, the cabinet
Thermistor 2 shorted. In plain terms, the evaporator
Thermistor 3 shorted. In plain terms, the third
The display has stopped answering the board
The cabinet sensor circuit is open
The evaporator sensor circuit is open
The room sensor circuit is open
The same digits mean different things on different equipment. Search the full code list
In more detail
About U-Line error code Evap T Short
What Evap T Short means, in the maker's own words
The evaporator thermistor circuit is shorted. The same sensor as Evap T Open and the opposite failure: the cable is pinched or crushed rather than broken or disconnected. Unlike the E numbers on the rest of this make, this one is shown to you: the 3000 Series monitors its inputs continuously and puts the notification on the user interface rather than only into a service log.
Quoted rather than interpreted
Evap T Short — Inspect thermistor cable for pinch points or damage. Replace if necessary.
From the service diagnosis guide, 3000 Series User Guide, in a User Guide & Service Manual downloaded from U-Line's own site. Nothing on this page is decoded beyond what that sentence says.
Where this notification actually lives
On your display, which on this make is the exception rather than the rule. The 3000 Series does not use the E numbers at all: it watches its inputs continuously and writes the notification on the user interface in plain words, so there is no hidden log to open and no key to hold. Every other U-Line in this catalog does the opposite — it logs the number in memory and shows you nothing but the door. If you are reading a phrase rather than a number, this is the series you own.
What to do about it
- Inspect the thermistor cable for pinch points or damage and replace it if necessary.
- Inspect the wire harness from the main control board for pinch points or damage and repair it.
- Expect the same frost story as the open circuit: defrost timing is what this sensor is for, so ice on the coil arrives before any change you can feel in the cabinet.
- If the unit has recently been serviced or reinstalled, say so when you book. A harness pinched on reassembly is the most common history for a short on a cabinet that worked the day before.
Where this goes next
The job this usually becomes is diagnostic visit, and every one of those pages carries a starting figure and the reasons that move it. If it turns out to be nothing — and on this make a real share of these are modes rather than problems — the visit ends there and you pay the diagnostic and nothing else, or call (305) 851-2207 and describe what the display is doing before booking anything.
u line evap t short error names a notification the 3000 Series puts on the display itself, which is what makes it different from every other number this maker logs.
This article is based on:
- Official manufacturer documentation
- Internal repair procedures
- Technician repair history
- Company quality standards
